Pulse Bag Dust Collector
Pulse bag dust collector for dry particulate capture and workshop dust control.
SKU: RST-DUST-COLLECTOR
Product Details
Continuous Heavy-Duty Industrial Particulate Filtration Systems
Engineered for demanding industrial air filtration applications, our Pulse Jet Bag Dust Collectors efficiently filter dry, fine, non-fibrous dust from high-volume process exhaust streams. Featuring automated reverse-pulse compressed air cleaning technology, these collectors operate continuously without interrupting airflow, maintaining high filtration performance and low differential pressure.
Key Features & Advantages
- High Dust Removal Efficiency: Premium woven/non-woven filter media achieve collection efficiencies up to 99.9%+ for sub-micron particulate matters (PM2.5 / PM10).
- Automated Pulse-Jet Cleaning: Sequential, timer- or pressure-differential-controlled compressed air blasts clean filter bags online without stopping system operation.
- Advanced Filter Media Options: Wide selection of filter media (Polyester, PTFE membrane, Nomex, PPS, Fiberglass) tailored for high temperatures, moisture, or chemical aggressiveness.
- Heavy-Duty Construction: Rugged carbon steel housing with reinforced stiffeners designed to withstand continuous negative or positive operating pressures.
- Easy Maintenance & Bag Replacement: Features top-access clean-air plenum doors and tool-free filter bag snap-ring installation for quick servicing.
Technical Specifications
| Parameter | Standard Range / Capability |
| Housing Material | Carbon Steel (A36) / Stainless Steel 304/316 |
| Airflow Processing Range | 2,000 to 200,000+ m³/h |
| Filtration Efficiency | Up to 99.99% (Outlet emission < 10 mg/m³) |
| Operating Temperature | Ambient up to 260°C (with specialized media) |
| Cleaning Mechanism | Pulse Jet Air Cleaning (0.4 - 0.6 MPa compressed air) |
| Discharge Mechanisms | Rotary Airlock Valve, Screw Conveyor, or Manual Slide Gate |
Typical Applications
- Cement, Lime, & Gypsum Processing
- Mining, Crushing, & Quarry Operations
- Metallurgy, Steelmaking, & Foundry Fume Extraction
- Woodworking, Furniture, & Biomass Dust Control
- Grain Handling, Feed Mills, & Food Processing
- Chemical Powder Handling & Bagging Lines
Request a Custom Quote
Send us your particulate type, airflow volume, gas temperature, and dust concentration for a custom Pulse Jet Dust Collector recommendation.
